功能特點 FUNCTIONAL
|
純不銹鋼防盜門天地桿鎖體，國標通用尺寸 Stainless stell mortise,National standard dimension. |
|
純不銹鋼材質鎖板及把手，堅固耐用 Stainless Steel panels and handles, staudy and durable. |
|
一卡通Mifarel感應芯片 Mifare 1 RF card. |
|
高強度觸摸密碼屏，防盜窺視密碼輸入功能 High frequency password screen,with anti-peeking password inputting function. |
|
備用機械鎖芯采用超C級葉片鎖芯 Spare mechanical key with ultra clockcore. |
|
上提打反鎖功能 Handle Lifed locking |
|
多用戶管理 Multi-management |
|
低電壓報警功能 Low voltage alarm funtion |
|
可選配遙控器開啟 Remote control is useful. |
技術參數 TECHNOLOGY
|
感應卡片技術 Card technology |
一卡通Mifarel感應芯片 Mifare 1 RF card |
|
用戶容量 User capacity |
密碼用戶數量100組，卡用戶數量800組 100 passwords, 800 cards. |
|
工作電壓 Working voltage |
DC6V直流電池 DC6V ,DC battery. |
|
工作溫度 Working temperature |
-30~ +60°C |
|
工作濕度 Working humidity |
40%~85% RH (無凝霜) |
|
感應卡工作頻率 Frequency |
13.56MHz |
|
感應卡類型 Card Model |
可選擇: 標準卡片式、扣鈕式、貼膜式。 Standard formula, Buttoning style, Thin Film style. |
|
功耗 Power Consumption |
靜態功耗≤20微安。動態功耗≤200毫安。 Static current:≤20 uA,Dynamic current :≤200 mA |
|
密碼長度 Password length |
6-10位 6-10 digits |
|
適用門類型及厚度 Door Thickness |
適用于國標帶天地桿防盜門，厚度40-120mm Door thickness for 40- 120mm |
|
面板尺寸 Panel size |
長:315 寬:74 厚:26 Length:315 Width:74 Thickness:26 |
